Female straight 7/8" (5-pole) IDC terminals Connection cross section: 0.75...1.5 mm² Plastic housings with good resistance against chemicals and oils. The...
Poids
0,094 kg
Pays d'origine
RO
Désignation du modèle
7/8''Buchse ger.5p.MOSA 0,75-1,5qmm
Family construction form
7/8"
No. of poles
5
Gender
female
Mounting method
inserted, screwed, Shaking protection
Threaded hole
7/8"
Tightening torque
1,5 Nm
Cable outlet
straight
Current operating per contact max.
10 A
Current phase - neutral
230 V
Current phase - phase
400 V
Single wire diameter min.
0,15 mm
Connection cross section min.
0,75 mm²
