Male straight – female straight 7/8" – 7/8", 5-pole Power cable Further cable lengths on request. Plastic housings with good resistance against chemicals...
Weight
0,195 kg
Country of origin
CZ
Model designation
MSCBL0-CA-U961_0.8
Cable length
0,80 m
Family construction form
7/8"
No. of poles
5
Gender
Female
Mounting method
inserted, screwed, Shaking protection
Threaded hole
7/8"
Tightening torque
1,5 Nm
Width across flats
SW22
Cable outlet
straight
suitable for corrugated tube (internal Ø)
15,8 mm
Degree of protection (EN IEC 60529)
IP67
Current operating per contact max.
10 A
