7/8'' female 0° / Push Pull Power AIDA
Price excluding VAT
Request a quote
Female straight – female straight Push Pull Power - 7/8" female Plastic housings with good resistance against chemicals and oils. The resistance to...
Weight
1,130 kg
Country of origin
CZ
Model designation
MSCBL0-WPA-U962_5.0
Cable length
5,00 m
Family construction form
7/8"
No. of poles
5
Gender
female
Mounting method
pluggable, screwed
Cable outlet
straight
Material
Zinc die-casting
Degree of protection (EN IEC 60529)
IP65
Tightening torque
1,5 Nm
Width across flats
SW22
suitable for corrugated tube (internal Ø)
15,8 mm
Operating voltage AC max.
24 V
