WT12-2N130 | Functional principle: Photoelectric proximity sensor | Functional principle detail: Background suppression | Switching output: NPN | Switching mode: Light/dark switching | Connection type: Cable, 2 m | Light source: LED | Adjustment: Potentiometer
Functional principle
Photoelectric proximity sensor
Functional principle detail
Background suppression
Dimensions (W x H x D)
15 mm x 49 mm x 41.5 mm
Housing design (light emission)
Rectangular
Sensing range max.
20 mm ... 250 mm1)
Sensing range
20 mm ... 250 mm1)
Type of light
Visible red light
Light source
LED
Adjustment
Potentiometer
Supply voltage
10 V DC ... 30 V DC
Ripple
< 5 Vpp
Current consumption
40 mA1)
Switching output
NPN
Switching mode
Light/dark switching
Response time
≤ 330 µs2)
Connection type
Cable, 2 m3)
Cable material
PVC
Conductor cross section
0.25 mm²
Cable diameter
Ø 5 mm
Housing material
Metal, zinc diecast
Optics material
Plastic, PMMA
Enclosure rating
IP69K
Ambient operating temperature
–40 °C ... +60 °C
Ambient temperature, storage
–40 °C ... +75 °C
UL File No.
NRKH.E181493 & NRKH7.E181493
