WS/WE27-2R630 | Functional principle: Through-beam photoelectric sensor | Switching mode: Light/dark switching | Connection type: Connector Q6, 6-pin, AC/UC-coding | Light source: LED
Functional principle
Through-beam photoelectric sensor
Dimensions (W x H x D)
24.6 mm x 80 mm x 53.5 mm
Housing design (light emission)
Rectangular
Sensing range max.
0 m ... 35 m
Sensing range
0 m ... 15 m
Type of light
Visible red light
Light source
LED
Supply voltage
24 V DC ... 240 V DC
Switching mode
Light/dark switching
Response time
< 6 ms1)
Connection type
Connector Q6, 6-pin, AC/UC-coding
Housing material
Plastic, ABS
Optics material
Plastic, PMMA
Enclosure rating
IP65
Ambient operating temperature
–40 °C ... +60 °C
Ambient temperature, storage
–40 °C ... +75 °C
UL File No.
NRKH.E181493 & NRKH7.E181493
