Photoelectric sensors | W12-2 Laser | WS/WE12L-2P430 | Sensing range max.: 0 m ... 80 m | Functional principle: Through-beam photoelectric sensor | Switching output: PNP | Connection type: Male connector M12, 4-pin | Light source: Laser | Type of light: Visible red light | Laser class: 2 | Adjustment: Potentiometer | Housing: Rectangular | Included with delivery: 2 x clamps BEF-KH-W12, incl. screws
Functional principle
Through-beam photoelectric sensor
Sensing range max.
0 m ... 80 m
Light source
Laser1)
Type of light
Visible red light
Light spot size (distance)
Ø 150 mm (60 m)
Normative reference
EN 60825-1:2014, IEC 60825-1:2007
Laser class
22)3)
Wave length
650 nm
Adjustment
Potentiometer
Special applications
Detecting small objects, Detection of objects moving at high speeds
Items supplied
2 x clamps BEF-KH-W12, incl. screws
Part number of individual components
2021722 WS12L-2D430 2021726 WE12L-2P430
MTTFD
396 years
DCavg
0 %
TM(mission time)
10 years
Supply voltage UB
10 V DC ... 30 V DC1)
Ripple
< 5 Vpp2)
Current consumption, sender
≤ 45 mA3)
Current consumption, receiver
≤ 15 mA3)
Protection class
III
Type
PNP
Signal voltage PNP HIGH/LOW
Uv - < 2.9 V, Uv V / 0 V <= 1.5 V
Signal voltage NPN HIGH/LOW
Uv - < 2.9 V, Uv V / 0 V <= 1.5 V
Output current Imax.
≤ 100 mA
Response time
≤ 200 µs4)
Switching frequency
2,500 Hz5)
Output function
Complementary
Circuit protection
A6)C7)D8)
Dimensions (W x H x D)
15 mm x 49 mm x 41.5 mm
Connection
Male connector M12, 4-pin
Housing
Metal
Front screen
Plastic, PMMA
Weight
260 g
Enclosure rating
IP67IP69K
Ambient operating temperature
–10 °C ... +50 °C
Ambient temperature, storage
–25 °C ... +75 °C
UL File No.
NRKH.E181493 & NRKH7.E181493
EU declaration of conformity
✔
UK declaration of conformity
✔
ACMA declaration of conformity
✔
Moroccan declaration of conformity
✔
China RoHS
✔
cULus certificate
✔
Laser safety (IEC 60825-1) certificate
✔
ECLASS 5.1.4
27270903
ECLASS 6.0
27270903
ECLASS 7.0
27270903
ECLASS 8.0
27270903
ECLASS 9.0
27270903
ECLASS 10.0
27270903
ECLASS 11.0
27270903
ECLASS 12.0
27270903
ECLASS 13.0
27270903
ECLASS 14.0
27270903
ECLASS 15.0
27270903
ETIM 6.0
EC002719
ETIM 7.0
EC002719
ETIM 8.0
EC002719
ETIM 9.0
EC002719
ETIM 10.0
EC002719
UNSPSC 091201.0
32151804
UNSPSC 100501.0
32151804
UNSPSC 111201.0
32151804
UNSPSC 120901.0
32151804
UNSPSC 131201.0
32151804
UNSPSC 140801.0
32151804
UNSPSC 151101.0
32151804
UNSPSC 160901.0
32151804
UNSPSC 171001.0
32151804
UNSPSC 180801.0
32151804
UNSPSC 190501.0
32151804
UNSPSC 200601.0
32151804
UNSPSC 210901.0
32151804
UNSPSC 220601.0
32151804
UNSPSC 230701.0
32151804
UNSPSC 240301.0
32151804
UNSPSC 250901.0
32151804
UNSPSC 260801.0
32151804
