WLL160-E122 | Switching output: NPN | Switching mode: Light/dark switching | Connection type: Cable, 2 m | Light source: LED
Dimensions (W x H x D)
12 mm x 38.5 mm x 59 mm
Housing design (light emission)
Rectangular
Sensing range max.
0 mm ... 2,000 mm1)
Sensing range
0 mm ... 400 mm1)
Type of light
Visible red light
Light source
LED
Wave length
660 nm
Supply voltage
10 V DC ... 30 V DC
Ripple
± 10 %
Current consumption
30 mA1)
Switching output
NPN
Switching mode
Light/dark switching
Response time
≤ 0.35 ms2)
Connection type
Cable, 2 m3)
Cable material
PVC
Conductor cross section
0.2 mm²
Housing material
Plastic, ABS
Optics material
Plastic, PMMA
Enclosure rating
IP67
Ambient operating temperature
–25 °C ... +55 °C
Ambient temperature, storage
–40 °C ... +70 °C
UL File No.
NRNT2.E128350 & NRNT8.E128350
ECLASS 5.0
27270905
ECLASS 5.1.4
27270905
ECLASS 6.0
27270905
ECLASS 6.2
27270905
ECLASS 7.0
27270905
ECLASS 8.0
27270905
ECLASS 8.1
27270905
ECLASS 9.0
27270905
ECLASS 10.0
27270905
ECLASS 11.0
27270905
ETIM 5.0
EC002651
ETIM 6.0
EC002651
ETIM 7.0
EC002651
ETIM 8.0
EC002651
UNSPSC 16.0901
39121528
