RFID transponders | UHF transponders | UHF Transponder, Rectangular, On-Metal, global | Carrier frequency: 865 MHz ... 928 MHz | Special features: High Temperature | Memory capacity (EPC / user memory): 496/128 Bit (EPC / User Memory) | Dimensions (L x W x H): 47.5 mm x 51.5 mm x 10 mm
Product segment
RFID transponders, RFID
Product
UHF transponders
Scope
Marking of metal parts that are exposed to high temperatures, liquids and chemicals, UV-resistant
Specialty
High Temperature
Frequency band
UHF (860 MHz ... 960 MHz)
Carrier frequency
865 MHz ... 928 MHz
Design
Rectangular
Housing material
Thermoplastic
Ambient operating temperature
–40 °C ... +85 °C1)
Storage temperature
–40 °C ... +85 °C
Application temperature
+ 125 °C, 60 min, 12)
Housing color
Gray
IC type
Impinj M780
Storage capacity
496/128 Bit (EPC / User Memory)
IC data retention time
< 20 years
Mounting method
Screws, Rivets
Dimensions (W x H x L)
51.5 mm x 10 mm x 47.5 mm
Вес
+ 22 g
RFU61x
70 cm3)
RFU62x
150 cm3)
RFU63x/RFU65x
700 cm3)
ECLASS 5.1.4
0
ECLASS 6.0
0
ECLASS 7.0
0
ECLASS 8.0
0
ECLASS 9.0
27280402
ECLASS 10.0
27280402
ECLASS 11.0
27280402
ECLASS 12.0
27280402
ECLASS 13.0
27280402
ECLASS 14.0
27280402
ECLASS 15.0
27280402
ETIM 6.0
EC002996
ETIM 7.0
EC002996
ETIM 8.0
EC002996
ETIM 9.0
EC002996
ETIM 10.0
EC002996
UNSPSC 091201.0
43211710
UNSPSC 100501.0
43211710
UNSPSC 111201.0
43211710
UNSPSC 120901.0
43211710
UNSPSC 131201.0
43211710
UNSPSC 140801.0
43211710
UNSPSC 151101.0
43211710
UNSPSC 160901.0
43211710
UNSPSC 171001.0
43211710
UNSPSC 180801.0
43211710
UNSPSC 190501.0
43211710
UNSPSC 200601.0
43211710
UNSPSC 210901.0
43211710
UNSPSC 220601.0
43211710
UNSPSC 230701.0
43211710
UNSPSC 240301.0
43211710
UNSPSC 250901.0
43211710
UNSPSC 260801.0
43211710
