ReLy | RLY3-EMSS100 | Applications: Evaluation unit | Compatible sensor types: Safety sensors with potential-free outputs | Connection type: Front connector with spring terminals | Restart interlock: yes | External device monitoring (EDM): Integrated | Outputs: 2 enabling current paths (safe), 2 application diagnostic outputs (not safe), 3 test pulse outputs (not safe) | Housing width: 18 mm
Applications
Evaluation unit
Compatible sensor types
Safety sensors with potential-free outputs
Safety integrity level
SIL 3 (IEC 61508)
Category
Category 4 (ISO 13849-1)
Performance level
PL e (ISO 13849-1)
PFHD(mean probability of a dangerous failure per hour)
1.0 x 10-9
TM(mission time)
20 years (ISO 13849-1)
Stop category
0 (IEC 60204-1)
Sensor monitoring
Discrepancy monitoringCross-circuit detection
Restart interlock
✔
Reset
AutomaticManual
External device monitoring (EDM)
✔
Connection type
Front connector with spring terminals
Inputs
2 safety inputs1 input for reset pushbutton or external device monitoring (EDM)
Outputs
2 enabling current paths (safe)2 application diagnostic outputs (not safe)3 test pulse outputs (not safe)
Display elements
LEDs
Configuration method
Hard wired
Voltage supply
PELV or SELV
Supply voltage VS
24 V DC (16.8 V ... 30 V)
Residual ripple
≤ 2.4 V
Power consumption
≤ 2.5 W (DC)
Activation time tolerance between the two start buttons
≤ 3 s
Input voltage HIGH
24 V DC (11 V ... 30 V)
Input voltage LOW
0 V DC (–3 V ... 5 V)
Input current
4 mA ... 6 mA
Response time (opening of enabling current paths)
10 ms
Contact material
Silver alloy, gold flashed
Switching voltage
10 V AC ... 230 V AC
Switching current
10 mA ... 6 A
Total current
12 A
Mechanical life
1 x 107switching cycles
Overvoltage category
III (EN 60664-1)
Rated impulse withstand voltage Uimp
6 kV (EN 60664-1)
Output voltage HIGH
≥ Vs– 3 V
Output voltage LOW
≤ 3 V
Input current (NPN)
≤ 15 mA
Output current (PNP)
≤ 120 mA
Number
3
Type of output
PNP semiconductors, short-circuit protected
Output voltage
≥ Vs– 3 V
Test pulse width
2 ms
Test pulse interval
40 ms
Dimensions (W x H x D)
18 mm x 124.6 mm x 85.5 mm
Weight
130 g
Enclosure rating
IP20 (IEC 60529)
Ambient operating temperature
–25 °C ... +55 °C
Storage temperature
–25 °C ... +70 °C
Air humidity
≤ 95 %, Non-condensing
Interference emission
According to IEC 61000-6-4
Interference resistance
According to IEC 61326-3-1According to IEC 61000-6-2According to IEC 60947-5-1
EU declaration of conformity
✔
UK declaration of conformity
✔
ACMA declaration of conformity
✔
China RoHS
✔
CCC certificate
✔
UK-Type-Examination approval
✔
cULus certificate
✔
EAC certificate / DoC
✔
cTUVus certificate
✔
S Mark certificate
✔
EC-Type-Examination approval
✔
EC-Type-Examination approval (Machinery Directive)
✔
EC-Type-Examination approval (Machinery Regulation)
✔
Third party certificate
✔
