3× 400 V AC RC Suppressors for other voltages, frequencies, and motor ratings available on request. Do not use RC motor suppressors with frequency inverters.
Weight
0,125 kg
Country of origin
CZ
Model designation
HRC 3/022-400/4
Power frequency
50 ... 60 Hz
Input voltage AC
400 V
Connection cross-section stranded/fine-stranded min.
0,5 mm²
Length single strands
250 mm
Connection information
Single cores with self-securing fork terminal ends M4
Flame resistance
flame retardant
Material housing
Plastic
Combustibility class housing (UL94)
V-0
Material potting compound
2-component epoxy
Height
75 mm
Width
45 mm
Depth
42 mm
