SUB-D9; SUB-D9 2× SUB-D9 (female/female)
Weight
0,040 kg
Country of origin
DE
Model designation
Fr. Modul MSDD 2x9 pol. Bu/Bu
Height
88 mm
Width
51 mm
Depth
15 mm
Ambient temperature (storage, transport)
-30 °C … 60 °C
Family construction form
SUB-D9
Gender
female
No. of poles
9
Looking techniques
Standard UNC 4-40 screw thread bolt (EN 60807)
Family type Back side
SUB-D9
Gender Rear
female
Operating voltage AC
48 V
Operating voltage DC
48 V
