Expansion module DI4 - 0.2 A DO4 - 2 A (E) - 8× M12 (Y) Y-wiring Connection cables are in the online shop under "Connection Technology". Housing fully...
Weight
0,220 kg
Country of origin
CZ
Model designation
MASI68 DI4 DO4 Y E 8xM12
Total current max.
4 A
Bus voltage AS-Interface DC min.
26,5 V
Bus voltage AS-Interface DC max.
31,6 V
Current consumption AS-i port max.
250 mA
Current carrying capacity max.
0,2 A
Short-circuit protected
Yes
Overload resistant
Yes
Type input
for 3-wire sensors or mechanical switches, PNP
Output current per pin max.
2 A
Address setting type
M12 connection and programming device, Master
Slave address range
(0), 1 ...
AS-i Power 24
Yes
