MASI67 converter 2× profile cable to M12 (male) Connection cables are in the online shop under "Connection Technology".
Вес
0,120 kg
Страна происхождения
DE
Обозначение модели
MASI67 Umsetzer 2x Profilk.-M12St
Operating voltage DC max.
36 V
Total current max.
4 A
Degree of protection (EN IEC 60529)
IP67
Insulation strength ASI/Power
200 V
Height
90 mm
Width
74 mm
Depth
39 mm
Mounting method
geschnappt, screwed
Suitable for mounting type
(EN 60715), mounting rail
Operating temperature min.
-20 °C
Operating temperature max.
60 °C
Ambient temperature (storage, transport)
-40 °C … 80 °C
