Fiber-optic sensors | Fiber-optic cables | LL3-TH07 | Functional principle: Through-beam system | Fiber-optic head design: Smooth sleeve, 90° deflection | Fiber length: 2,000 mm | Smooth sleeve diameter: 4 mm | Fiber material: Glass | Jacket material: Stainless steel | Fiber head material: Stainless steel
Device type
Fiber-optic cables
Functional principle
Through-beam system, consisting of a sender and a receiver
Fiber-optic head design
Smooth sleeve, 90° deflection
Application
Heat-resistant (≥100°C)
Compatible fiber-optic amplifiers
GLL70, WLL80, WLL180, GLL170(T)
Sensing range max.
600 mm (Sensing range of WLL80 at 8 ms)
Minimal object diameter
0.1 mm1)
Angle of dispersion
60°
Integrated lens
No
Compatibility tip adapters
No
Compatibility with infrared light
Yes2)
Adapter end sleeves required
No
Light emission
Radial
Smooth sleeve diameter
4 mm
Optical fiber taper diameter
≥ 1 mm
Optical fiber taper length after 2 mm
≥ 8 mm
Fiber length
2,000 mm
Bending radius
50 mm
Dynamic flexibility (robotics)
No
Outside diameter, optical fiber cable connection
2.2 mm
Fiber arrangement
Singlefiber
Core structure
Ø 0,5 mm Singlefiber
Optical fiber head
Stainless steel
Sheath
Stainless steel
Fibers
Glass
Weight
34 g
Ambient operating temperature
–60 °C ... +200 °C
Operating mode 4 ms
600 mm
Operating mode 500 µs
255 mm
Operating mode 1 ms
290 mm
Operating mode 16 µs
18 mm
Operating mode 70 µs
30 mm
Operating mode 2 ms
220 mm
Operating mode 8 ms
420 mm
Note
Sensing ranges related to fiber-optic sensors with type of light: visible red light
Operating mode 50 µs
50 mm
Operating mode 250 µs
90 mm
ECLASS 5.0
27270905
ECLASS 5.1.4
27270905
ECLASS 6.0
27270905
ECLASS 6.2
27270905
ECLASS 7.0
27270905
ECLASS 8.0
27270905
ECLASS 8.1
27270905
ECLASS 9.0
27270905
ECLASS 10.0
27270905
ECLASS 11.0
27270905
ECLASS 12.0
27270905
ETIM 5.0
EC002651
ETIM 6.0
EC002651
ETIM 7.0
EC002651
ETIM 8.0
EC002651
UNSPSC 16.0901
39121528
