Fiber-optic sensors | Fiber-optic cables | LL3-TA05 | Functional principle: Through-beam system | Thread diameter (housing): M2.6
Device type
Attachment lens for optical fiber cable
Functional principle
Through-beam system, consisting of a sender and a receiver
Special features
Suitable for detection with high sensing range / high robustness against contamination, 90° offset
Angle of dispersion
9°
Items supplied
2 pieces
Sleeve material
Brass (Br)
Lens material
Glass
Thread diameter (housing)
M2.6
Weight
2 g
Ambient operating temperature
–60 °C ... +300 °C
ECLASS 5.0
27270905
ECLASS 5.1.4
27270905
ECLASS 6.0
27270905
ECLASS 6.2
27270905
ECLASS 7.0
27270905
ECLASS 8.0
27270905
ECLASS 8.1
27270905
ECLASS 9.0
27270905
ECLASS 10.0
27270905
ECLASS 11.0
27270905
ECLASS 12.0
27270905
ETIM 5.0
EC002651
ETIM 6.0
EC002651
ETIM 7.0
EC002651
ETIM 8.0
EC002651
UNSPSC 16.0901
39121528
