Inductive proximity sensors | IMF | IMF08-04NPPNC0S | Housing: Standard design | Special applications: Hygienic and washdown zones, Difficult application conditions | Sensing range Sn: 4 mm | Installation type: Non-flush | Electrical wiring: DC 4-wire | Switching output: PNP | Output function: Complementary | Connection type: Male connector M12, 4-pin | Special features: Resistant to cleaning agents, Temperature resistance
Housing
Standard design
Thread size
M8 x 1
Diameter
Ø 8 mm
Sensing range Sn
4 mm
Safe sensing range Sa
3.24 mm
Installation type
Non-flush
Switching frequency
4,000 Hz
Connection type
Male connector M12, 4-pin1)
Switching output
PNP
Switching output detail
PNP
Output function
Complementary
Electrical wiring
DC 4-wire
Enclosure rating
IP682)IP69K3)
Special features
Resistant to cleaning agents, Temperature resistance
Special applications
Hygienic and washdown zones, Difficult application conditions
Items supplied
Mounting nut, V4A stainless steel (2x)
Supply voltage
10 V DC ... 30 V DC
Ripple
≤ 10 %
Voltage drop
≤ 2 V1)
Hysteresis
3 % ... 20 %
Reproducibility
≤ 2 %2)3)
Temperature drift (of Sr)
± 10 %
EMC
According to EN 60947-5-2
Continuous current Ia
≤ 200 mA
No load current
≤ 10 mA
Short-circuit protection
✔
Power-up pulse protection
✔
Shock and vibration resistance
100 g / 11 ms / 1000 cycles; 150 g / 1 Mio cycles; 10 Hz ... 55 Hz, 1 mm / 55 Hz ... 500 Hz / 15 g
Ambient operating temperature
–40 °C ... +100 °C
Housing material
Stainless steel V4A, DIN 1.4404 / AISI 316L
Sensing face material
Plastic, LCP
Housing length
60 mm
Thread length
28 mm
Tightening torque, max.
Typ. 14 Nm
Protection class
III
UL File No.
E181493
MTTFD
1,687 years
DCavg
0 %
TM(mission time)
20 years
Communication interface
IO-Link V1.0
Communication Interface detail
COM2 (38,4 kBaud)
Process data length
1 Byte
Process data structure
Bit 0 = Sr reachedBit 1 = Sa reached
Note
The values are reference values which may vary
Stainless steel (V2A, 304)
Approx. 0.69
Aluminum (Al)
Approx. 0.37
Copper (Cu)
Approx. 0.28
Brass (Br)
Approx. 0.4
Remark
Associated graphic see "Installation"
A
8 mm
B
18 mm
C
8 mm
D
12 mm
E
8 mm
F
32 mm
EU declaration of conformity
✔
UK declaration of conformity
✔
ACMA declaration of conformity
✔
Moroccan declaration of conformity
✔
China RoHS
✔
ECOLAB certificate
✔
FDA certificate
✔
cULus certificate
✔
IO-Link certificate
✔
Information according to Art. 3 of Data Act (Regulation EU 2023/2854)
✔
ECLASS 5.1.4
27270101
ECLASS 6.0
27270101
ECLASS 7.0
27270101
ECLASS 8.0
27270101
ECLASS 9.0
27270101
ECLASS 10.0
27270101
ECLASS 11.0
27270101
ECLASS 12.0
27274001
ECLASS 13.0
27274001
ECLASS 14.0
27274001
ECLASS 15.0
27274001
ETIM 6.0
EC002714
ETIM 7.0
EC002714
ETIM 8.0
EC002714
ETIM 9.0
EC002714
ETIM 10.0
EC002714
UNSPSC 091201.0
39121500
UNSPSC 100501.0
39121500
UNSPSC 111201.0
39121500
UNSPSC 120901.0
39121500
UNSPSC 131201.0
39122230
UNSPSC 140801.0
39122230
UNSPSC 151101.0
39122230
UNSPSC 160901.0
39122230
UNSPSC 171001.0
39122230
UNSPSC 180801.0
39122230
UNSPSC 190501.0
39122230
UNSPSC 200601.0
39122230
UNSPSC 210901.0
39122230
UNSPSC 220601.0
39122230
UNSPSC 230701.0
39122230
UNSPSC 240301.0
39122230
UNSPSC 250901.0
39122230
UNSPSC 260801.0
39122230
