Üksikasjalik kirjeldus puudub.
Version
High Density
Reading field
Front
Optical focus
Variable (through exchangeable lens) (flexible adaptable)
Sensor
XGA
Sensor resolution
1,024 px x 768 px (grayscale values)
Lens
CS- and C-mount
Reading distance
200 mm ... 3,000 mm1)
Scanning frequency
30 Hz
Connection type
1 x M12 8-pin male device connector (“Power, I/O”)1 x M12 4-pin female device connector, D-coded (“Ethernet”)1 x M12 8-pin female device connector (“RS-485”)
Supply voltage
≤ 24 V DC, ± 20 %
Power consumption
10 W
Housing material
Aluminum
Housing color
Light blue (RAL 5012), Black
Enclosure rating
IP541)
Protection class
III (VDE 0106, IEC 1010-1)
Kaal
505 g, without lens and connection cables
Dimensions (L x W x H)
160.6 mm x 60 mm x 54.5 mm2)
Bar code types
Data Matrix ECC200
No. of codes per scan
1 ... 1
Exposure time
64 µs ... 500 ms
Digital inputs
1 (Reading pulse trigger)
Digital outputs
3 (“Good Read”, “No Read”, “Trigger OUT”)
Reading pulse
Sensor input (“Trigger IN”), non-powered
Optical indicators
4 LEDs (status displays)
Electromagnetic compatibility (EMC)
EN 61000-6-2:2001-10 / EN 61000-6-4:2001-10
Vibration resistance
5 g, 58 Hz ... 150 Hz
Shock resistance
15 g, 3 x 6 directions
Ambient operating temperature
0 °C ... +50 °C
Storage temperature
–20 °C ... +70 °C
Permissible relative humidity
90 %, Non-condensing
Ambient light immunity
Depending on lens, aperture, illumination used
Life cycle phase
Discontinued
ECLASS 5.0
27280103
ECLASS 5.1.4
27280103
ECLASS 6.0
27280103
ECLASS 6.2
27280103
ECLASS 7.0
27280103
ECLASS 8.0
27280103
ECLASS 8.1
27280103
ECLASS 9.0
27280103
ECLASS 10.0
27280103
ECLASS 11.0
27280103
ECLASS 12.0
27280103
ETIM 5.0
EC002550
ETIM 6.0
EC002550
ETIM 7.0
EC002999
ETIM 8.0
EC002999
UNSPSC 16.0901
43211701
