GBIT module - male, crimp t.
GBIT module - male, crimp t.
Murrelektronik

GBIT module - male, crimp t.

SKU: 70MH-MAH1C-0000000 Доступно к заказу
Цена без НДС
Запросить цену

Запросить цену

    Male Gigabit Technical data will be only guaranteed with Murrelektronik components. The clip 70MH-ZZ100-0000000 is needed (2×)

    Вес
    0,055 kg
    Страна происхождения
    PL
    Обозначение модели
    MSMH-MSTM-1M-C-GBITMODUL
    Operating voltage AC
    50 V
    Operating voltage DC
    50 V
    Operating current
    5 A
    Transfer parameters
    CAT6A
    Connection cross section min.
    0,08 mm²
    Connection cross section max.
    0,5 mm²
    AWG number min.
    28
    AWG number max.
    20
    Gender
    male
    Connection
    Crimp
    Mating cycles min.
    500
    Stripping length
    4,2 mm
