Connectors and cables | Y- and T-splitters | FX3-MOC Y-CABLE | Description: Shielded, Y-cable to connect a Flexi Soft Motion Control Module FX3-MOC with two encoders (HTL, TTL, Sin/Cos, SSI). | Connection type head A: Male connector, Micro D-Sub, 15-pin, angled | Connection type head B: Female connector, M12, 8-pin, straight, A-coded | Connection type head C: Female connector, M12, 8-pin, straight, A-coded | Cable: 3.4 m, for details see dimensional drawings, PVC and PP
Connection type head A
Male connector, Micro D-Sub, 15-pin, angled
Connection type head B
Female connector, M12, 8-pin, straight, A-coded
Connection type head C
Female connector, M12, 8-pin, straight, A-coded
Locking plug connector
Screw connection
Connecting cable
3.4 m, for details see dimensional drawings, PVC and PP
Cable material
PVC and PP
Cable color
Black
Conductor cross section
AWG28, AWG26
Cable diameter
6.6 mm, 6.2 mm
Housing material
Plastic/metal
Housing color
Black
Locking nut material
Steel
Width across flats
Slot
Shielding
Shielded
Flexible use
> 10 x cable diameter
Stationary position
> 5 x cable diameter
Operating temperature
–25 °C ... +80 °C, stationary position–10 °C ... +80 °C, flexible use
Description
Y-cable to connect a Flexi Soft Motion Control Module FX3-MOC with two encoders (HTL, TTL, Sin/Cos, SSI).
EU declaration of conformity
✔
UK declaration of conformity
✔
ECLASS 5.0
19030312
ECLASS 5.1.4
19030312
ECLASS 6.0
27060304
ECLASS 6.2
27060304
ECLASS 7.0
27060304
ECLASS 8.0
27060304
ECLASS 8.1
27060304
ECLASS 9.0
27060304
ECLASS 10.0
27060304
ECLASS 11.0
27060304
ECLASS 12.0
27060304
ETIM 5.0
EC000830
ETIM 6.0
EC000830
ETIM 7.0
EC003249
ETIM 8.0
EC003249
UNSPSC 16.0901
26121604
