Female 5-pole Push-In terminals Technical data will be only guaranteed with Murrelektronik components. Please use wire end ferrule. The clip...
Вес
0,016 kg
Страна происхождения
PL
Обозначение модели
MSMH-MBUM-1M-P-5pol. 400 V 16 A
Operating voltage AC
400 V
Operating voltage DC
400 V
Operating current
16 A
Connection cross section min.
0,14 mm²
Connection cross section max.
2,5 mm²
AWG number min.
26
AWG number max.
14
Gender
female
Connection
Push-In spring clamp terminals
Mating cycles min.
500
No. of poles
5
Pollution Degree
3
