Murrelektronik
EOL - MASI ASI POWER SUPPLY 1-PHASE,
Price excluding VAT
Request a quote
INPUT: 230 V AC Current: 2.8 A Single-phase, primary switched Protection IP20 Unit complies to AS-Interface specification for power supplies (PELV)
Weight
0,650 kg
Country of origin
CZ
Model designation
MASI 2,8-230/30,5
Security level
SELV
Power frequency
50 ... 60 Hz
Input voltage 1 AC
230 V
Current input AC
0.8 A
Inrush current max.
20 A
Efficiency
85 %
Characteristic back-up fuse
Inertia
External back-up fuse per phase max.
10 A
Output voltage adjustable
no
Output voltage DC
305 V
Output voltage DC min.
29.58 V
Output voltage DC max.
31.42 V
