ELDV2-06-16MT-0025 - Injection 6-Port GC Diaphragm Valve

Built with precision and accuracy in mind, this 6-port 2-Position Injection & Switching Gas Chromatography Valve is engineered for long-lasting performance. It is constructed with high-grade 316L stainless steel for exceptional durability and corrosion resistance and certified leak tight up to 150 psi at 180°C, making it ideal for VOC applications.
Key Features:

Ports: 6
Temperature: 180°C
Pressure: 150 psi
Material: SS-316L
Port Size: 0.030”
Coating: None
Purge: None

Benefits Include:

Increased Productivity: No wear and tear components in proper conditions other than the diaphragm, which we recommend should be replaced approximately every 1 year as preventive maintenance
Ideal For: Fast switching and high duty cycle applications
Accurate Results: Superior seal integrity prevents inboard leaks

Higher Quality: Every valve is leak tested before shipping at no additional cost
