E-Stop 22 2NC M12(4) Emergency-Stop Mounting hole 22,3 mm Connection M12 (4-pin)
Kaal
0,039 kg
Päritoluriik
HU
Mudeli tähistus
E-Stop 22 2NC M12(4)
Rated operating voltage AC-15
35 V
Rated operating voltage DC-13
35 V
Short-circuit current
1.000 A
Voltage switching AC min.
1 V
Switching voltage AC max.
35 V
Voltage switching DC min.
1 V
Switching voltage DC max.
35 V
Switching voltage AC max. (UL 60947)
30 V
Switching voltage DC max. (UL 60947)
30 V
Switching current min.
1 mA
Switching current max.
100 mA
Switching power max.
0,25 W
