Male straight – male straight DRIVE-CLiQ IP67 - DRIVE CLiQ IP67 Further cable lengths on request. The resistance to aggressive media should be individually...
Weight
0,750 kg
Country of origin
DE
Model designation
M6FX8002-2DC20-1AJ5
Cable length
8,50 m
Family construction form
RJ45
Operating voltage AC max.
30 V
Operating voltage DC max.
30 V
Current operating per contact max.
27.760 A
Data transmission rate max.
100 Mbit/s
Transfer parameters
CAT5, Class D (ISO/IEC 11801:2002), (EN 50173-1)
duplex
Full duplex
Degree of protection (EN IEC 60529)
IP67
Pollution Degree
3
Rated surge voltage
0,5 kV
Material group (IEC 60664-1)
II
