Connectors and cables | Other connectors and cables | DOL-0803-G10MN | Description: Unshielded | Connection type head A: Female connector, M8, 3-pin, straight | Connection type head B: Flying leads | Cable: 10 m, 3-wire, PP | Connection systems: Flying leads | Application: Hygienic and washdown zones, Drag chain operation
Connection type head A
Female connector, M8, 3-pin, straight
Connection type head B
Flying leads
Connection type
Flying leads
Connector material
PP
Connector color
White
Locking nut material
Stainless steel (V4A/1.4404/316L)
Tightening torque
0.6 Nm
Cable
10 m, 3-wire, PP
Jacket material
PP
Jacket color
Blue-gray
Cable diameter
4.6 mm
Conductor cross section
0.34 mm²
Shielding
Unshielded
Current loading
4 A
Application
Hygienic and washdown zonesDrag chain operation
Enclosure rating
IP67/ IP69K
Flexible use
–40 °C ... +105 °C
Stationary position
–40 °C ... +105 °C
Head
–40 °C ... +105 °C
ECLASS 5.0
19030312
ECLASS 5.1.4
19030312
ECLASS 6.0
27060304
ECLASS 6.2
27060304
ECLASS 7.0
27060304
ECLASS 8.0
27060304
ECLASS 8.1
27060304
ECLASS 9.0
27060304
ECLASS 10.0
27060304
ECLASS 11.0
27060304
ECLASS 12.0
27060304
ETIM 5.0
EC000830
ETIM 6.0
EC000830
ETIM 7.0
EC003249
ETIM 8.0
EC003249
UNSPSC 16.0901
26121604
