Murrelektronik
CUBE67 Hygienic Design I/O EXTENSION MODULE
Prix hors TVA
Demander un devis
Expansion module DIO8 - 0.5 A (E) - 4× M12 short-circuit and overload protected Digital inputs/outputs (multifunctional) Hygienic Design Stainless steel,...
Poids
0,242 kg
Pays d'origine
DE
Désignation du modèle
Cube67 DIO8 E 4xM12 HD
Norm operating voltage
IEC/EN 61131-2
Operating voltage US DC
24 V
Total current US max.
4 A
Operating voltage UA DC
24 V
Total current UA max.
4 A
Current consumption max.
50 mA
Sensor current US per input max.
0,2 A
Short-circuit protected
Yes
Overload resistant
Yes
Input filter time
1 ms
Type input
for 3-wire sensors or mechanical switches, PNP
Output current per pin max.
0,5 A
