Junction boxes | CDB | CDB620-101 | Brief description: Small connection module for one sensor, 2 cable glands, 2 x M12 connector/socket for CAN, base for CMC600 | Communication interface: SerialCAN | Communication Interface detail: RS-232 | Operating voltage: 10 V DC 30 V DC | Supported products: CLV61x - CLV65xLector62xRFH6xxRFU62x
Brief description
Small connection module for one sensor, 2 cable glands, 2 x M12 connector/socket for CAN, base for CMC600
Supported products
CLV61x - CLV65xLector62xRFH6xxRFU62x
Cloning module support (CMC)
Yes
Supports display module (CMD)
No
Supports power supply module (CMP)
No
Supports fieldbus gateway (CMF)
No
Supply voltage
(10 V DC ... 30 V DC)1)
Power consumption
1 W
Housing
Polycarbonate
Enclosure rating
IP65
Protection class
III
Weight
260 g
Dimensions (L x W x H)
124.2 mm x 113.1 mm x 53.9 mm
Scanner connection
15-pin D-Sub HD female connector
Service plug
9-pin D-Sub plug (internal)
Serial
✔ , RS-232, RS-422, RS-485
CAN
✔
Remark
Depending on sensor connected
Digital inputs
Depending on sensor connected
Digital outputs
Depending on sensor connected
Optical indicators
9 LED
Configuration software
SOPAS ET
Ambient operating temperature
–35 °C ... +40 °C
Storage temperature
–35 °C ... +70 °C
Permissible relative humidity
≤ 90 %, Non-condensing
EU declaration of conformity
✔
UK declaration of conformity
✔
ACMA declaration of conformity
✔
China RoHS
✔
cULus certificate
✔
4Dpro
✔
