BNS044H (BNS 819-X939-B02-D08-40-10) - Multiple position: Special - Housing material: Aluminium, Anodized, Number of switching positions: 2x Chisel, Version: Snap contact, Operating principle: 1-2. Switch position: Mechanical, Continuous current: 1-2. Switch position: 4 A, Rated operating voltage Ue: 1-2. Switch position: 60 V, Installation: Vertical, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 1-2. Switch position: 20 m/min, Ambient temperature: -5...85 °C, IP rating: IP67, Approval/Conformity: CE, UKCA, CCC, WEEE
Housing material
Aluminium, Anodized
Number of switching positions
2x Chisel
Version
Snap contact
Operating principle
1-2. Switch position: Mechanical
Continuous current
1-2. Switch position: 4 A
Rated operating voltage Ue
1-2. Switch position: 60 V
Installation
Vertical
Approach direction
longitudinal, parallel to attachment surface
Approach speed
1-2. Switch position: 20 m/min
Ambient temperature
-5...85 °C
IP rating
IP67
Approval/Conformity
CEUKCACCCWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Manual
BNS 819/813 40 | (German, English)
Tariff Code
85365080
Substances of concern
Download
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
