BNS01N6 (BNS 819-X512-D03-E12-62-10) - Multiple position: Special - Housing material: Aluminium, Anodized, Number of switching positions: 3x E-Chisel, Version: Snap contact, Operating principle: 1-3. Switch position: Mechanical, Continuous current: 1-3. Switch position: 6 A, Rated operating voltage Ue: 1-3. Switch position: 250 V AC, Installation: Vertical, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 1-3. Switch position: 30 m/min, Connection type: 1-3. Switch position: Screw terminal, Ambient temperature: -5...85 °C, IP rating: IP67, Approval/Conformity: CE, CCC, WEEE
Housing material
Aluminium, Anodized
Number of switching positions
3x E-Chisel
Version
Snap contact
Operating principle
1-3. Switch position: Mechanical
Continuous current
1-3. Switch position: 6 A
Rated operating voltage Ue
1-3. Switch position: 250 V AC
Installation
Vertical
Approach direction
longitudinal, parallel to attachment surface
Approach speed
1-3. Switch position: 30 m/min
Connection type
1-3. Switch position: Screw terminal
Ambient temperature
-5...85 °C
IP rating
IP67
Approval/Conformity
CECCCWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Tariff Code
85365080
Disposal instructions
Download
