BNS04MU (BNS 819-D02-D12-100-10-FD-S90F) - Mechanical multiple position limit switches - Housing material: Aluminium, Anodized, Number of switching positions: 2x Chisel, Version: Snap contact, Operating principle: 1-2. Switch position: Mechanical, Continuous current: 1-2. Switch position: 5 A, Rated operating voltage Ue: 1-2. Switch position: 6…60 V, Installation: Vertical, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 1-2. Switch position: 40 m/min, Connection type: 1. Switch position: Connector, Ambient temperature: -5...85 °C, IP rating: IP67, Approval/Conformity: CE, WEEE
Housing material
Aluminium, Anodized
Number of switching positions
2x Chisel
Version
Snap contact
Operating principle
1-2. Switch position: Mechanical
Continuous current
1-2. Switch position: 5 A
Rated operating voltage Ue
1-2. Switch position: 6…60 V
Installation
Vertical
Approach direction
longitudinal, parallel to attachment surface
Approach speed
1-2. Switch position: 40 m/min
Connection type
1. Switch position: Connector
Ambient temperature
-5...85 °C
IP rating
IP67
Approval/Conformity
CEWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Manual
BNS 100/62/61 819 | (German, English)
Tariff Code
85365080
