BIS00ZF (BIS M-622-070-A01-03-ST33) - HF RFID processors (13.56 MHz) - List price Deutschland: 2.046,43 EUR - Product group: HF (13.56 MHz), Interface: Profibus DP Slave galvanically isolated, Supported RFID technologies: HF 13.56 MHz (BIS M), Number of connectable R/W heads / antennas: 1, Operating voltage Ub: 19.2...28.8 VDC, Housing material: Aluminium, Ambient temperature: -20...50 °C, IP rating: IP65, with connector, Approval/Conformity: CE, UKCA, cULus, WEEE, Connection: M12x1-Male, 5-pin, B-coded, M12x1-Female, 5-pin, B-coded, M12x1-Male, 5-pin
Product group
HF (13.56 MHz)
Interface
Profibus DP Slave galvanically isolated
Supported RFID technologies
HF 13.56 MHz (BIS M)
Number of connectable R/W heads / antennas
1
Operating voltage Ub
19.2...28.8 VDC
Housing material
Aluminium
Ambient temperature
-20...50 °C
IP rating
IP65, with connector
Approval/Conformity
CEUKCAcULusWEEE
Connection
M12x1-Male, 5-pin, B-codedM12x1-Female, 5-pin, B-codedM12x1-Male, 5-pin
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity | (All languages)
Manual
BIS M-62_ PROCESSOR UNIT | (English) | ABx fast Protocol | CBx Protocol | BIS Dashboard | BIS C-Macro Builder | BIS M-622-070-A01-03-ST33 | (English)
Supplement
CYBERSECURITY RFID | (German, English) | SAFETY INSTRUCTIONS
Tariff Code
85437090
Substances of concern
Download
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
