BIS00HE (BIS C-60R-002-08P-PU-10) - LF read/write heads (70/455 kHz) with integrated processor unit - Product group: LF (70/455 kHz), Dimension: Ø 30 x 95 mm, Installation: metal-free (clear zone), Antenna type: round, Connection: Cable (shielded), 15-pin, 10.00 m, PU, Housing material: Brass, nickel-plated, Interface: 8x8 bits parallel, Ambient temperature: 0...50 °C, IP rating: IP67, Approval/Conformity: CE, WEEE, EAC
Product group
LF (70/455 kHz)
Installation
metal-free (clear zone)
Antenna type
round
Connection
Cable (shielded), 15-pin, 10.00 m, PU
Housing material
Brass, nickel-plated
Interface
8x8 bits parallel
Ambient temperature
0...50 °C
IP rating
IP67
Approval/Conformity
CEWEEEEAC
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Manual
BIS C-60R-00.-08P-... | (German)
Tariff Code
85437090
Disposal instructions
Download
