BIS00A7 (BIS C-602-019-653-03-KL2) - LF RFID processors (70/455 kHz) - Product group: LF (70/455 kHz), Interface: Profibus DP galvanically isolated, Supported RFID technologies: LF 70/455 kHz (BIS C ), Number of connectable R/W heads / antennas: 1, Operating voltage Ub: 19.2...28.8 VDC, Housing material: ABS, Ambient temperature: 0...60 °C, IP rating: IP65, with read/write head, Approval/Conformity: CE, UL-FILE E227256, Vol.X1, BIS, Connection: Terminal strip, 19-pin
Product group
LF (70/455 kHz)
Interface
Profibus DP galvanically isolated
Supported RFID technologies
LF 70/455 kHz (BIS C )
Number of connectable R/W heads / antennas
1
Operating voltage Ub
19.2...28.8 VDC
Housing material
ABS
Ambient temperature
0...60 °C
IP rating
IP65, with read/write head
Approval/Conformity
CEUL-FILE E227256, Vol.X1, BIS
Connection
Terminal strip, 19-pin
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Manual
BIS C-6.. LESEK. | (German, English) | BIS C-602-019.. | (German) | BIS C-6_2 HW-ERGAENZUNG | (German)
Supplement
BIS UL ERGAENZUNG | (German)
Tariff Code
85437090
