BES00LH (BES 516-3026-E4-Y-02) - Inductive proximity switches and proximity sensors - Dimension: Ø 18 x 45.5 mm, Style Housing: M18x1, Installation: non-flush, Range: 8 mm, Switching output: PNP normally closed (NC), Switching frequency: 200 Hz, Housing material: Brass, nickel-plated, Material sensing surface: PA 12, Connection: Cable, 2.00 m, PVC, Operating voltage Ub: 10...30 VDC, Ambient temperature: -25...70 °C, IP rating: IP67, Approval/Conformity: CE, cULus, EAC
Style Housing
M18x1
Installation
non-flush
Range
8 mm
Switching output
PNP normally closed (NC)
Switching frequency
200 Hz
Housing material
Brass, nickel-plated
Material sensing surface
PA 12
Connection
Cable, 2.00 m, PVC
Operating voltage Ub
10...30 VDC
Ambient temperature
-25...70 °C
IP rating
IP67
Approval/Conformity
CEcULusEAC
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Taric code
85365019
