Mounting systems | Brackets | BEF-AD-G14-G12A-PXX SCREW-IN ADAPTER | Description: Process adapter for pressure sensors with G 1/4” female thread; attachment on sensor side: G 1/4”B (according to EN 837-1) including seal (stainless steel); connection on process side: G 1/2”A (according to EN ISO 1179-2) including seal (NBR+FKM); width across flats: 27; pressure resistance according to standard, but max. 400 bar (possible classification according to Pressure Equipment Directive (DGRL) is application-specific and therefore the responsibility of the user/operating entity.) | Material: Stainless steel | Details: Stainless steel 1.4404
Accessory group
Mounting systems
Accessory family
Brackets
Material
Stainless steel 1.4404
Description
Process adapter for pressure sensors with G 1/4” female thread; attachment on sensor side: G 1/4”B (according to EN 837-1) including seal (stainless steel); connection on process side: G 1/2”A (according to EN ISO 1179-2) including seal (NBR+FKM); width across flats: 27; pressure resistance according to standard, but max. 400 bar (possible classification according to Pressure Equipment Directive (DGRL) is application-specific and therefore the responsibility of the user/operating entity.)
ECLASS 5.1.4
27279202
ECLASS 6.0
27279202
ECLASS 7.0
27279202
ECLASS 8.0
27279202
ECLASS 9.0
27273701
ECLASS 10.0
27273701
ECLASS 11.0
27273701
ECLASS 12.0
27273701
ECLASS 13.0
27273701
ECLASS 14.0
27273701
ECLASS 15.0
27273701
ETIM 6.0
EC002467
ETIM 7.0
EC002467
ETIM 8.0
EC002467
ETIM 9.0
EC002467
ETIM 10.0
EC002467
UNSPSC 091201.0
32131000
UNSPSC 100501.0
32131000
UNSPSC 111201.0
32131000
UNSPSC 120901.0
32131000
UNSPSC 131201.0
32131023
UNSPSC 140801.0
32131023
UNSPSC 151101.0
32131023
UNSPSC 160901.0
32131023
UNSPSC 171001.0
32131023
UNSPSC 180801.0
32131023
UNSPSC 190501.0
32131023
UNSPSC 200601.0
32131023
UNSPSC 210901.0
32131023
UNSPSC 220601.0
32131023
UNSPSC 230701.0
32131023
UNSPSC 240301.0
32131023
UNSPSC 250901.0
32131023
UNSPSC 260801.0
32131023
Download Datasheet
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
