A10 male 15-pole, crimp t., 250 V, 10 A
A10 male 15-pole, crimp t., 250 V, 10 A
A10 male 15-pole, crimp t., 250 V, 10 A
Murrelektronik

A10 male 15-pole, crimp t., 250 V, 10 A

SKU: 70MH-ES015-BC01010 Saadaval tellimisel
Hind käibemaksuta
Küsi pakkumist

Küsi pakkumist

    A10 Male 15-pole Crimp Technical data will be only guaranteed with Murrelektronik components.

    Kaal
    0,033 kg
    Päritoluriik
    CZ
    Mudeli tähistus
    MSMH-EST-A10-C-15pol. 250 V 10 A
    Operating voltage AC
    250 V
    Operating voltage DC
    250 V
    Operating current
    10 A
    Connection cross section min.
    0,14 mm²
    Connection cross section max.
    2,5 mm²
    AWG number min.
    26
    AWG number max.
    13
    Gender
    male
    Connection
    Crimp
    Mating cycles min.
    500
    Wire insulation diameter min.
    4,3 mm
    No. of poles
    15 + PE
